Flanged Pressure Reducing Valve, 05-044FL
Additional information
| Connection Type | Flanges acc. to DIN EN 1092 PN10 |
|---|---|
| Material Body | Brass |
| Inner Parts | Brass |
| Seat Sealing | NBR |
| Temperature Range | 0°C to 70°C |
- Piston balanced seat
- Inlet pressure 40 bar,
- Outlet press. 0,5-16 bar
| Art. Nr. | DN | PN | L | H | ØD |
| 05-044FL-15 | DN15 | PN40 | 130 | 160-260 | 95 |
| 05-044FL-20 | DN20 | PN40 | 150 | 160-260 | 105 |
| 05-044FL-25 | DN25 | PN40 | 160 | 160-260 | 115 |
| 05-044FL-32 | DN32 | PN40 | 180 | 160-260 | 140 |
| 05-044FL-40 | DN40 | PN40 | 200 | 160-260 | 150 |
